Dual Display

Dual Display 32"

SPECIFICATIONS

Panel

Screen Size

32inch (81.28mm) diagonal

Panel Type

LGD IPS Panel, RGB

Resolution

1920x1080(FHD)

Viewing Angles

R/L 178º , U/D 178º

Brightness(cd/m²)

2000nit(Window Facing)/

1000nit(Indoor Facing)

Panel Interface

LVDS 2ch

Back light

Edge Type

Operating system

Indoor facing

OS

Android 9.0


CPU

Rockchip RK3288 4-core ARM Cortex A53


GPU

4-core ARM Mali-450


Memory

RAM : DDR4 2GB / ROM : eMMC 16GB


Network

Wi-Fi 2.4G/5G, 802.11 a/b/g/n/ac

BT 4.2


I/O Port

USB 2.0 x1, RJ45 x 1


Display Operation System

Window Facing Clone interface

Android interface

Window facing

OS

Android 7.1


CPU

Rockchip RK3288 4-core ARM Cortex A17


GPU

4-core ARM Mali-T764


Memory

RAM : DDR3 2GB / ROM : eMMC 8GB


Network

Wi-Fi 2.4G/5G(Option), 802.11 a/b/g/n/ac

BT 4.2


I/O Port

USB 2.0 x1, RJ45 x 1


Display Operation System

Android interface

Touch

Type

In-Cell

Multi Touch Point

10 points

Active Touch area

Same as LCD Active area

Operation

Power Consumption

 170W (Typ.)/ Stan-by : <3W

Power Supply(SMPS)

AC 100~240V /50~60Hz

Landscape/Portrait

Portrait Only

Operating Temperature

0º C~40º C



Mechanical Specification

Dimension

Set(W x H x D)

448.65 x 754.2 x 69.4mm

Carton(W x H x D)

TBD

Weight

Set(Kg)

22.0Kg

Package(Kg)

TBD
