QSR series
QSR 32" Touch
SPECIFICATIONS
Screen Size
32inch (81.28mm) diagonal
Panel Type
LGD IPS Panel, RGB
Resolution
1920x1080(FHD)
Viewing Angles
R/L 178º , U/D 178º
Brightness(cd/m²)
2000nit(Center 1 point,Typ.)
Panel Interface
LVDS 2ch
Color Gamut
NTSC 72%
Back light
Edge LED
Glass
Thickness
3T,Hard Coating(7H)
Surface Treatment
AG, Light transmittance ≥ 89%
Chipset
MSD3683
1920 x 1080
Component(Mini.)
480i,480p,720p,1080i,1080p
HDMI 1,2
HDMI Ver.:1.4
HDCP Ver.:1.4
CEC: HDMI 1,2
ARC: HDMI 2
Display Port
EXT. ALS
Ambient Light Sensor 3.5mm jack
CVBS(Mini.)
480i,576i
USB
Software Upgarde, Multimedia play
SPDIF
Optical
Audio Out(L/R)
Earphone
RS232
3.5mm Earphone jack
LAN
RJ45(Ethernet)
Touch Type
Advanced In-cell Touch
Active Touch Area
Same as LCD active area
Multi Touch Point
10 Points
OS
Android 9.0
RAM
2GBytes(DDR4)
ROM
16GBytes(eMMC)
Bluetooth 4.1
Wi-Fi
802.11 b/g/n/ac(Dual Band 2.4G /5G)
Power Consumption
120W (Typ.)/ Stan-by : <3W
Power Supply(SMPS)
AC 100~240V /50~60Hz
Weatherproof Rate
IP 66
Landscape/Portrait
Yes
Operating Temperature
-20º C~40º C
(Direct sunlight)
Set(W x H x D)
465.0 x 763.4 x 55.8mm
Carton(W x H x D)
850.0 x 550.0 x 150.0mm
Set(Kg)
20.0Kg
Package(Kg)
25.0Kg
Download
320TXF2R-GW
NEWOPTICS_QSR_air_32_320TXF2R-GW.PDF
QSR_32_320TXF2R-GW_drawing.PDF
